Connecting
5.6 Mounting Temperature Sensors
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
83
To disable the ZeroMatic function:
1. Select the [Install Sensor] menu cell from the [Dual Path Flow] menu.
2. Scroll down to the [Zero Flow Adjust] menu cell by pressing <Up/Down Arrow>.
Note
The highlighted [ZeroMatic] menu item is the only indication that ZeroMatic is
functioning.
3. Invoke the ZeroMatic initial makeup procedure as previously described above.
4. While ZeroMatic initial makeup is running, press <Left Arrow> to abort the process
thereby disabling the function.
5. The screen will return to the [Dual Path Flow] menu and highlight the [Operation Adjust]
menu cell.
Mounting Temperature Sensors
Temperature is used to normalize the liquids sonic velocity in order to properly determine
interfaces and for density determination. Temperature sensors are available in clamp-on
style or in insert (Thermowell) style. Refer to the table below. Both styles incorporate 1000
ohm platinum RTD’s for high precision.
Table 5- 4 Temperature Sensors
Standard clamp-on RTD 7ME39501TA00
Submersible clamp-on RTD (not for FUP1010 or FUE1010
Standard clamp-on RTD pair for FUE1010 energy system
Insertion style RTD (size 1): 140mm (5.5 in)
Insertion style RTD (size 2): 216mm (8.5 in)
Insertion style RTD (size 3): 292mm (11.5 in)
Insertion style RTD (size 4): 368mm (14.5 in)
Insertion style RTD pair (size 1) for FUE1010, 140mm (5.5 in)
Insertion style RTD pair (size 2) for FUE1010, 216mm (8.5 in)
Insertion style RTD pair (size 3) for FUE1010, 292mm (11.5 in)
Insertion style RTD pair (size 4) for FUE1010, 368mm (14.5 in)
