7.1 Selecting Flow Units

FUE1010 IP65 NEMA 4X

Operating Instructions, 12/2014, A5E03086491-AC

101

Table 7- 2 Totalizer Controls (the "n" in <Fn> = channel number)*

Key

PC #

Command

Description

CLRTOT

(also clears over-

flow)

Resetting the Totalizer registers clears all total data accumulated during operation.

Note: In Dual Path mode, the Totalizer operates only on the virtual system channel

(Ch 3). Therefore in this case, the CLRTOT trigger would be <F3> <1>.

Commands that can be invoked from Si-Ware or HyperTerminal:

Terminal Command: CLRTOT 1.

NOTOT

(Totalizer Freeze)

Invoking the NOTOT command disables the Totalizer. Totalization will not resume

until you repeat the <Fn> <2> key sequence. When you activate NOTOT, an N pre-

cedes the TOTAL symbol (i.e. [NTOTAL]) on the LCD Screen.

Commands that can be invoked from Si-Ware or HyperTerminal:

Terminal Command: NOTOT 1 = Stop Totalizer

Terminal Command: NOTOT 1 = Start Totalizer

LAPTOT

(Totalizer snap-

shot)

The LAPTOT command freezes the Totalizer screen display. However, the flow

meter will continue to update its internal registers. The flow meter will show the cur-

rent total when you repeat the <F1>< 3> key sequence. When you activate LAPTOT,

an L precedes the TOTAL symbol (i.e., [LTOTAL]) on the HyperTerminal screen.

CLEAR

(Batch/Tot regis-

ter)

Clears the Batch/Sample Totalizer register. The flow meter maintains a separate

Totalizer register for Batching or Sampling applications but cannot be accessed

directly. It is used for relay control only. If you assign the system relay to this func-

tion, a momentary (200 ms) relay pulse occurs whenever the BATCHTOT register

accumulates a specified liquid quantity. In the [Batch/Sample Tot] menu cell the

required total flow volume is entered to activate the relay,. This numeric entry must

reflect the selected flow total units. The [Totalizer Scale] menu cell shows the appli-

cable flow total units. The sign of the Batch/Sample Total determines positive or

negative accumulation.

CLEAR

(Makeup Latch)

Clears the Makeup Latch. Refer to the Span Data menu [Set Alarm Levels] and then

the [Makeup Latch] On / Off option.

*Use the <F1> key as the "Lead-in command" for 4-Path Totalizer operations.
