Installing/mounting
4.5 Mounting the Transmitter
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
33
● Avoid mounting on or near weld seams.
● Pipe must be full to achieve proper operation.
May cause death or serious personal injury.
Disconnect power before working on this product.
The transmitter can be mounted on any wall surface including wood, metal or concrete. Use
the appropriate bolts and screws as needed for your mounting application and adhere to
local codes. (See figure below for mounting bracket locations.)
For installation on 2-inch (6 cm) mounting pipe use Pipe Mount Kit CQO:1012NMB-1
(optional - see catalog). See figure below.
Note
Pipe mounting kit CQO:1012NMB
-1 is not available for IP66 NEMA 7 enclosures.
