Functions
7.7 Analog Out Setup
FUE1010 IP65 NEMA 4X
116 Operating Instructions, 12/2014, A5E03086491-AC
Memory Map
Selecting [YES] for this item enables a snapshot display of current memory usage. In this
display, the asterisk indicates a used memory block, a space indicates a free block, while a
dash character indicates unused filler.
Defragment
Selecting [YES] for this item consolidates memory data blocks into contiguous storage;
collapsing the filler regions. You may be able to use an additional block for site or Datalogger
storage as a result. Use this command if you seem to be out of memory even though the
[Log Memory Left] item indicates free capacity.
7.7
Analog Out Setup
The flow meter provides current, voltage and pulse-rate analog outputs. The [Analog Out
Setup] menu allows you to assign data functions for these signals. The transmitter terminal
strip contains the analog output terminals.
Table 7- 6 Analog Outputs
Io
(Isolated Current) 4 to 20mA varies in proportion to an assigned
data function.
Vo
(DC Voltage) 0 to 10 VDC varies in proportion to an assigned
data function.
Pgen
(TTL Logic) 0 to 5000 Hz varies in proportion to an assigned
data function.
Table 7- 7 Analog Out Setup Data Categories
Vfo
Spanned volumetric/mass flow.
Vfo2
Additional Spanned volumetric/mass flow.
Vf
Spanned unsigned flow magnitude.
Vs
Spanned liquid sonic velocity.
Valc
Receive signal amplitude.
Vaer
Relative degree of liquid aeration/cavitaion.
Ve
Spanned instantaneous energy rate.
Ts
Spanned supply temperature.
Tr
Spanned return temperature.
Td
Spanned temperature difference (delta).
CE
Spanned Chiller efficiency rate.
