Connecting
5.3 Navigating the Menu
FUE1010 IP65 NEMA 4X
46 Operating Instructions, 12/2014, A5E03086491-AC
5.3
Navigating the Menu
Menu Navigation and Initial Power-up
Before you can navigate the menu you must first power-up the flowmeter. Follow the
instructions below to ensure safe connection of power to the meter and then proceed to the
menu navigation.
NOTICE
Power Supply Damage
Improper power connections will damage power supply.
Ensure that all AC or DC power supply connections are properly connected to the
appropriate power source (100-250 VAC @ 50/60 Hz or 9-36 VDC).
WARNING
Electrical Shock Hazard
Certain parts inside the device carry dangerous high voltage and contact may lead to fire,
electric shock, or serious personal injury.
The transmitter must be grounded and the top cover closed before applying power to the
device.
Power-Up Procedure
1. Connect the power cables to the appropriate power source (100-240 VAC @ 50/60 Hz or
9-36 VDC). Close top cover.
2. Apply power.
3. Within 10 seconds of power-up the main display will become active and a typical Siemens
graphic will appear. The screen also identifies the software version of the unit as shown
below.
