Siemens SITRANS FUE1010 IP65 NEMA 4X User Manual

Connecting
5.3 Navigating the Menu
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
47
①
Software Version (x.xx.xx)
4. Press the <MENU> key and the Main Menu will appear. (Language selection is not on
Version 3 op system.)
The Installation Menu Chart is a multi-level structure divided into three columns from left to right
Level A - lists the major menu categories.
Level B
- list the menu cells associated with Level A. You can enter data into Level B menu cells that
are display parameters in a column at the right of the screen.
Level C - lists the Level B data
Level A
Level B
Level C
Recall Site Setup
Pump 1
Pump 2
Channel Enable
Create/Name Site
Site Security
Delete Site Setup
Save/Rename Site
