Connecting
5.5 Sensor Installation
FUE1010 IP65 NEMA 4X
62 Operating Instructions, 12/2014, A5E03086491-AC
10.Sensors can now be mounted. Refer to Sensor Installation mounting procedures and
select the mounting mode desired.
11.
After sensors are mounted scroll to [Install Complete] and select [Install].
Reflect Mount
Reflect Mount - Sensor Installation using Mounting Frames and Spacer Bar
1. After receiving the spacing index from the Installation Menu, prepare the pipe surface
area where the sensors will be mounted.
2. Degrease the surface and remove any grit, corrosion, rust, loose paint, etc.
Before beginning refer to the Reflect Mount Installation diagram example below.
Optional: On larger pipes, multiple lengths
of straps can be linked together to sur-
Space Bar Platform & Clamping Screw
Mounting Strap positioned around Mount-
Space Bar (Front View)
Sensor shown in the 9 o'clock position on
Metal Post
Mounting Strap Adjusting Screw
Figure 5-12 Reflect Mount with Mounting Frames and Spacer Bar
Note
Minimum Ltn 18 mm (0.75 in).
