Safety notes
2.6 Safety Notes
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
19
● Intrinsically safe connections Class I and II, Division 1, Groups A, B, C, D, E, F and G;
● Nonincendive for Class I, Division 2, Groups A, B, C and D;
● Suitable for Class II, Division 2, Groups E, F and G outdoor (Type 4X), Class III (CSA
only)
● Temperature code T5 at an ambient of 40°C
● Intrinsically safe Class I and II, Division 1, Groups A, B, C, D, E, F and G;
● Nonincendive for Class I, Division 2, Groups A, B, C and D;
● Suitable for Class II, Division 2, Groups E, F and G outdoor (Type 4X), Class III (CSA
only)
● Temperature code T6 at an ambient of 40°C
Read, understand and follow all safety instruction on the electronic media provided. This
equipment complies with Directive 94/9/EC and is rated for use in potentially explosive
atmospheres. The equipment markings are shown and explained below. Equipment must be
installed according to the 1010-389 installation drawing provided on the media. Failure to
install the equipment in the prescribed manner will result in unsafe operation. Follow all
regional safety laws when operating this equipment. When properly installed the equipment
meets the following ATEX ratings as stated in EC-Type Examination Certificate
KEMA03ATEX1134
Transmitter Markings and Explanations
● II (1) G [Ex ia] IIC – Transmitter located in the non-hazardous area with intrinsically
safe circuits of category Ex ia, which can be connected to Category 1 Sensors
●
II 3 (1) G Ex nC [ia] IIC T5 – Category 3 Transmitter located in Zone 2 explosion
atmosphere with intrinsically safe circuits of category Ex ia, which can be connected to
Category 1 Sensors in Zone 0
● IP65 – Ingress protection against solid bodies, rating of dust-tight and against liquid,
rating of water jets
Sensor Markings and Explanations
● II 1 G Ex ia IIC T5 – Category 1 Sensors located in Zone 0 explosive atmosphere with
intrinsically safe circuits of category Ex ia for use in potentially explosive atmosphere
containing gases
● IP65 – Ingress protection against solid bodies, rating of dust-tight and against liquid,
rating of water jets
