Connecting
5.5 Sensor Installation
FUE1010 IP65 NEMA 4X
Operating Instructions, 12/2014, A5E03086491-AC
73
The combination of two Model 1012TN Mounting Tracks and a spacer guide is the
recommended way to mount sensors in the Direct Mode. This method ensures that sensors
will align exactly 180° from each other and remain spaced the proper distance apart.
The Direct Mount configuration uses a set of two track rail assemblies; one for each sensor,
installed 180° apart on the pipe. The set includes:
● Reflect Mode Track Assembly - This track rail includes the Tension Screw and REF hole
to position one sensor.
● Direct Mode Track Assembly - This track rail has number index holes for inserting an
index pin to position the other sensor.
Note
A pin will be inserted into the hole designated by the Number Index on the Direct Mode
track rail to position one of the sensors (see
⑩ in figure below).
