Siko AP10 User Manual

Communication via CAN bus (CANopen)
AP10 Date: 28.02.2022 Art. No. 86853 Mod. status 37/22 Page 32 of 78
Name
Description
see
page
2003h: Calibration enable
Setting whether calibration of the display is enabled
via key actuation.
55
2004h: Incremental measurement
enable
Setting whether setting of the incremental
measurement function is enabled via key actuation.
55
2005h: Configuration enable via
keyboard and delay of start of
configuration
Setting whether configuration is enabled via key
operation. Delay of start of configuration.
55
5000h: Diagnosis of CAN bus errors
Informs about CAN bus error events.
56
5F09h: External Heartbeat timer
and external Heartbeat source
Cycle time and trigger source of the external
heartbeat.
57
5F0Ah: Node-ID, Auto-ID and Baud
rate Bus CAN
Setting of Node-ID baud rate.
58
5F0Bh: Display in the 2
nd
row
Setting of the display in the 2
nd
row.
59
5F0Ch: Control word
Control word
59
5F0Dh: Differential value and
difference formation
Differential value and setting of difference
formation.
60
5F10h: Target window1 (near
field)
Setting of target window1 (close-up range).
60
5F11h: Decimal places
Number of decimal places.
61
5F12h: Display orientation and
LEDs
Setting of the display orientation and LED
functionality.
61
5F13h: Display divisor (ADI) and
ADI application
Setting of the display divisor and its application.
64
5F14h: Loop length
Setting of the loop length.
65
5F15h: Positioning type
Setting of the loop type's direction of approach.
65
5F16h: Read target value
Read current target value; write access only via PDO.
65
5F19h: Status word
Output of the device status.
67
5F1Bh: Sensor type and operating
mode
Reading sensor type and setting of the operating
mode (absolute, differential display, 360°, alpha-
numeric display).
67
5F1Ch: Acknowledgement settings
Setting of the key to be used as acknowledgement
key (alpha-num. display).
68
5F1Fh: Direction indicators (CW,
CCW)
Setting of the appearance of the direction arrows.
68
5F21h: Target window2 (far) and
target window2 visualization
Setting of target window2 and its visualization.
69
6000h: Operating Parameters
Setting of scaling and sense of rotation.
70
6001h: Measuring steps per
revolution (Display per revolution
= APU)
Setting of the measuring steps per revolution
displayed
(Display per revolution = APU).
70
6002h: Total of measuring steps
Indicates the total of measuring steps of the system.
71
6003h: Preset value (calibration
value)
Setting of the calibration value.
71
6004h: Position value
Position value (offset against calibration and offset
value)
71
