5.7.2.53 6200h: Cycle Timer
Object 6200h sets a cycle time for the output of PDO1. This value is permanently linked to the
object 1800h: 1. Transmit PDO Parameter sub-index 5. Timer-controlled output is active as
soon as a valid cycle time has been entered and the device run in the Operational Mode. The
value 0 deactivates the function.
Sub-index
00h
Description
cycle Timer
Access
rw
PDO mapping
no
Data type
UNSIGNED 16
Default
0h
EEPROM
yes
Data content
0 … 65535
5.7.2.54 6500h: Operating Status
Object 6500h indicates the settings programmed with object 6000h.
Sub-index
00h
Description
Operating Status
Access
ro
PDO mapping
no
Data type
UNSIGNED 16
Default
4h
EEPROM
no
Data content
Bit 15 … 3
not used
Bit 2
0: Scaling disabled
1: Scaling enabled
Bit 1
not used
Bit 0
0: Clockwise sense of rotation I (CW)
1: Counter-clockwise sense of rotation E (CCW)
5.7.2.55 6501h: Single-turn resolution
Object 6501h indicates the physical number of measuring steps per revolution.
Sub-index
00h
Description
physical resolution
Access
ro
PDO mapping
no
Data type
UNSIGNED 32
Default
880
EEPROM
no
