Siko AP10 User Manual

Communication via CAN bus (CANopen)
AP10 Date: 28.02.2022 Art. No. 86853 Mod. status 37/22 Page 61 of 78
5.7.2.37 5F11h: Decimal places
The object 5F11h indicates the number of decimal places.
Sub-index
00h
Description
number of decimal places
Access
rw
PDO mapping
no
Data type
UNSIGNED 8
Default
0h
EEPROM
yes
Data content
0 … 4
5.7.2.38 5F12h: Display orientation and LEDs
Settings of the display orientation and the LEDs can be made via object 5F12h. Furthermore,
the function of the display backlighting can be set (see chapter 3.3).
Sub-index
00h
Description
indicates the largest sub-index supported
Access
ro
PDO mapping
no
Data type
UNSIGNED 8
Default
9h
EEPROM
no
Sub-index
01h
Description
Display orientation
Access
rw
PDO mapping
no
Data type
UNSIGNED 8
Default
0h
EEPROM
yes
Data content
0 = 0°
1 = 180° rotated
