Communication via CAN bus (CANopen)
AP10 Date: 28.02.2022 Art. No. 86853 Mod. status 37/22 Page 64 of 78
5.7.2.39 5F13h: Display divisor (ADI) and ADI application
The display divisor and its application can be changed via object 5F13h.
Sub-index
00h
Description
indicates the largest sub-index supported
Access
ro
PDO mapping
no
Data type
UNSIGNED 8
Default
2h
EEPROM
no
Sub-index
01h
Description
display divisor ADI
Access
rw
PDO mapping
no
Data type
UNSIGNED 8
Default
0h
EEPROM
yes
Data content
0: 1
1: 10
2: 100
3: 1000
Sub-index
02h
Description
ADI application
Access
rw
PDO mapping
no
Data type
UNSIGNED 8
Default
0h
EEPROM
yes
Data content
0: on all values
1: only on display. Values transferred via the interface are not offset
against the ADI.
