Page 4 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
U 10.
Close and lock the panel door.
All system electronics shipments include a small cardboard box (or boxes) containing
the system cards. Each box is marked as shown in Figure 2
Figure 2 System Card Box Label
Install the system cards in the system electronic bays after installation of the back
box and completion of the system field wiring.
To install the system cards, perform the following procedure:-
1. Make sure that the system ground wire is attached to the green lug screw in
the back box.
2. Inventory the contents of the system card box(es) on a flat surface.
• Open the system card box(es) and remove the cards.
• Refer to the factory documentation that accompanies the shipment.
3. Carefully install the Master Controller Card in the left hand slot on the Master
Motherboard, located in the CPU bay (See Figure 3.)
4. 4100 Panels: Carefully install the RS-232/2120 Communication Card
(if Supplied) in the right hand slot on the Master Motherboard (See Figure 3).
5. 4120 Network Panels: Carefully install the RS-485 Network Interface Card in the
right hand slot on the Master Motherboard (See Figure 3).
-CAUTION-
INSTALLER
THIS PACKAGE CONTAINS
CRITICAL COMPONETS
FOR INSTALLATION INTO ,
AND OERATION OF,
THIS UNIT

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
