Simplex 4100 - Audio Systems

SIMPLEX 4100 EWIS Page 31
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
3.2 EMERGENCY ALARM INITIATING DEVICES TERMINATIONS
Figure 13 Monitor Card Terminations for Manual Call Points
ZN1 ZN2 ZN4ZN3
ZN5 ZN6 ZN8ZN7
3k3
EOLR
Other Manual
Call Point Zones
5002
Monitor Card
Other Manual
Call Point Zones
