Simplex 4100 Installation Manual

SIMPLEX 4100 EWIS Page 17
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
Circuit Type Meter Reading
Style B (formerly Class B) Initiating Device (Zone) Circuit
From zone + to zone – (each zone) 3.3K ohms
From zone + to ground Infinity
From zone – to ground Infinity
Style D (formerly Class A) Initiating Device (Zone) Circuit
From zone + to zone – (each zone) Infinity
From zone + to ground Infinity
From zone – to ground Infinity
From zone + OUT to + IN Less than 50 ohms
From zone – OUT to – IN Less than 50 ohms
Style Y (formerly Class B) Notification Appliance Circuit (each signal circuit)
From + to ground Infinity
From – to ground Infinity
Resistance across circuit
In one direction 10K ohms
In opposite direction Less than 200 ohms
Style Z (formerly Class A) Notification Appliance Circuit (each signal circuit)
From + to ground Infinity
From – to ground Infinity
From + OUT to + IN Less than 50 ohms
From – OUT to – IN Less than 50 ohms
Resistance across circuit
In one direction Infinity
In opposite direction Less than 200 ohms
Shielding
Shield to ground Infinity
Shield to – Infinity
Shield to + Infinity
Table 1 Acceptable Zone and Signal Circuit Meter Readings

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
