Simplex 4100 Installation Manual

SIMPLEX 4100 EWIS Page 65
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
5. PLACING SYSTEM INTO OPERATION
Before undertaking any activities inspect the interior visually and check that all panel
equipment is securely mounted, and that all cables are connected at the appropriate
points.
5.1 POWER UP PROCEDURES
When power is first applied to the panel, or when the processor has been reset, the
system will self-test the integrity of its memory and verify proper card installation. At
the end of the self-test, the system will display “SYSTEM STARTUP IN PROGRESS”
followed by at least two fault conditions (battery and time and date). After the battery
is connected and the time and date has been entered, the system should then
display the message “SYSTEM IS NORMAL” along with the time and date.
Notes:
(i) When a printed circuit board is not properly inserted, the system will
display a fault condition.
(ii) When a printed circuit board is inserted, but configured incorrectly or
not defined in software, the system will display a fault condition, normal
operation will be suspended for that card until the fault has been
corrected.
(iii) Other failures will cause a message to be displayed to the operator,
may cause the system to become inoperative and the tone alert to
sound continuously.
Refer Appendix A for a list of Fault Messages and likely causes and
rectification

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
