Simplex 4100 Installation Manual

SIMPLEX 4100 EWIS Page 13
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
Figure 7 Mounting the door on the Back Box
14. Close and lock the panel door.
2.3 INSTALL AND TAG ALL SYSTEM WIRING.
• See the SYSTEM POINT SUMMARY Report (Table 7) and the appropriate
page in the 4100 Field Wiring Diagram (841-731).
2.4 INSTALL THE PERIPHERAL DEVICES AND E.O.L. RESISTORS.
• See Section 3 Field Terminations for details of terminating peripheral
devices.
• See the Point Type column in the SYSTEM POINT SUMMARY Report for
device type.
NOTES:
A. The 748-200 System Hardware envelope contains the required
resistors.
• 3.3K (monitor zone) resistors are colour coded orange, orange, red
(and have a gold tolerance band); 10K (Notification appliance [signal]
circuit) resistors are colour coded brown, black, orange (and also have
a gold tolerance band).
• Resistors other than those described above will be used by the
Simplex Technical Representative (T.R.) during installation checkout.
B. Wire peripherals in accordance with the appropriate 4100 Field Wiring
Diagram (841-731).
C. Use a small screwdriver or ball point pen to set device address switches.
D. After setting the device address, mark the device’s address label
(Figure 9) to agree with the address switches.

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
