Simplex 4100 Installation Manual

SIMPLEX 4100 EWIS Page 23
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
1 2 3 4 5 6 7 8
MSB LSB
Side View of Dip Switch
ON
OFF
SW-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
CPU MODULE IS ALWAYS ADDRESS 0
CPU = ADDRESS 0
U ON ON ON ON ON ON OFF = ADDRESS 1
S ON ON ON ON ON OFF ON = ADDRESS 2
E ON ON ON ON ON OFF OFF = ADDRESS 3
D ON ON ON ON OFF ON ON = ADDRESS 4
ON ON ON ON OFF ON OFF = ADDRESS 5
F ON ON ON ON OFF OFF ON = ADDRESS 6
O ON ON ON ON OFF OFF OFF = ADDRESS 7
R ON ON ON OFF ON ON ON = ADDRESS 8
ON ON ON OFF ON ON OFF = ADDRESS 9
B ON ON ON OFF ON OFF ON = ADDRESS 10
A ON ON ON OFF ON OFF ON = ADDRESS 11
U ON ON ON OFF OFF ON ON = ADDRESS 12
D ON ON ON OFF OFF ON OFF = ADDRESS 13
ON ON ON OFF OFF OFF ON = ADDRESS 14
R ON ON ON OFF OFF OFF OFF = ADDRESS 15
A ON ON OFF ON ON ON ON = ADDRESS 16
T ON ON OFF ON ON ON OFF = ADDRESS 17
E ON ON OFF ON ON OFF ON = ADDRESS 18
CONTINUES TO A BINARY 119
ON OFF OFF OFF ON OFF OFF OFF = ADDRESS 119
Table 2 Printed Circuit Board Addresses

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
