Simplex 4100 Installation Manual

SIMPLEX 4100 EWIS Page 81
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
9. APPENDIX B - EWIS 4100 FAULT MESSAGES
9.1 CARD TROUBLES
If the LCD displays ... Wrong Card Abnormal
 1st Line Shows Card Expected at this Address.
Reprogram System or Insert Proper Daughter Card.
If the LCD displays ... Extra Card Abnormal
 A Daughter Card is/was installed but not Programmed.
Reprogram System or Remove Extra Daughter Card.
 Warm Start is Necessary to Clear this Trouble Condition. Press the CPU
Reset Switch located on the Master Controller Board.
If the LCD displays ... Card Missing/Failed
 Identify Card from LCD.
 Is Communication Trouble LED illuminated on Card ?
 Check Dipswitch Setting with Programmer’s Report.
 Check for 8VDC & 24VDC at Motherboard Harness P3.
 Check for Serial Comm at Motherboard Harness P2.
 If ALL Daughter Cards Report Missing/Failed Check Serial Comm fuse on
Master Controller Board (F6).
) If this Trouble only Occurs upon Alarm, Alarm Silence or System Reset it may be
Caused by Unsuppressed Relays, Door Magnets, High Current Loads, etc.

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
