Page 82 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
9.2 BATTERY TROUBLES
If the LCD displays ... Master Battery Backup Status is Trouble
 Check connector P9 on Master Power Supply.
 Check that Batteries Terminals are Connected.
 Check Fuse(s) in the Battery Harness.
 Check for Charger Output at Battery Harness Terminals with the Batteries
Disconnected.
 Measure Battery voltage with Terminals from Harness Disconnected. (>18
VDC)
 Test Batteries under load for 1 minutes. (>23 VDC)
9.3 EARTH GROUNDS
If the LCD displays ... Master Earth Status is Trouble
 Is Ground on Positive/Negative side of Power Supply ?
 If a Positive Ground ... Remove half of the Motherboards.
Isolated to a Row ... Remove half of the Daughter cards.
 If a Negative Ground ... Check Power, and Shields.
 Ground could be Internal to the Control Panels.

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
