Page 78 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
8.3 GENERAL SYSTEM FAULTS
FAULT / STATUS POSSIBLE CAUSE SOLUTION
Mains ON indicator is OFF
• Mains at Distribution
board is OFF.
• Mains Switch is OFF.
• Mains Fuse Blown.
• Turn Power ON.
• Turn Mains Switch ON.
• Replace Fuse 8 Amp.
System on Batteries
• Mains at Distribution
board is OFF.
• Mains Power Failure.
• Mains Switch off.
• Mains Fuse Blown.
• Turn Power ON, check
for mains on indicator
when power is
returned.
• Turn Mains Switch ON.
• Replace Fuse 8 Amp.
Charger Fault
• Mains Fail.
• High volts:
Charger output volts
above 28.5 volts.
• Low volts:
Charger output volts
below 24.5 volts.
• Batteries fault:
Voltage below 24.5
volts
• Batteries Disconnected
• Reference mains on
indicator, and System
on batteries. Fault
status.
• Replace Power Supply.
• Replace Power Supply.
• Replace Batteries
• Connected Batteries

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
