SIMPLEX 4100 EWIS Page 63
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
4.12 NETWORK INTERFACE REPORT
The Network Interface Report specifies the network points associated with the node
and identifies them as either Public Points or External Points (points referenced from
other nodes).
--------------------------------------------------------------------------------------
XYZ BUILDING 1 NETWORK INTERFACE REPORT Page 154
909015J node:1 rev:1 5:20:54, THU, 08-MAY-97
--------------------------------------------------------------------------------------
Network Node : 1
Network Filename : SXNET
Master Timekeeper : YES
Annunciate Missing Node : YES
Point Device Point
Pt Typ Name Type Type Custom Label
---- --- ----------- ------- ------- ----------------------------------------
1 PUB 1:1 COMNTBL TROUBLE COMMON TROUBLE POINT FOR NODE: 1
2 PUB P210 DIGITAL UTILITY NETWORK DETECTOR RESET
3 PUB P211 DIGITAL UTILITY NETWORK SYSTEM RESET
4 PUB P212 DIGITAL UTILITY DETECTOR/SYSTEM RESET
5 PUB P217 DIGITAL UTILITY NETWORK SIGNAL SILENCE
6 PUB P132 DIGITAL TROUBLE ANALOG SENSOR ALMOST DIRTY LOG ENABLE
7 PUB P134 DIGITAL TROUBLE CLEAR ANALOG SENSOR PEAK VALUE
8 PUB P214 DIGITAL TROUBLE CLEAR VERIFICATION TALLIES
9 PUB P187 DIGITAL UTILITY VTG & AMPLIFIER TROUBLE DISABLE
10 PUB P47 DIGITAL UTILITY SIGNALS/VISUALS ACTIVE
11 PUB P85 DIGITAL UTILITY VTG 1 - ACTIVE
12 PUB P220 DIGITAL UTILITY NETWORK PRIORITY 2 RESET
13 PUB P221 DIGITAL UTILITY SIGNALS ACTIVE - OFF ON SILENCE
14 PUB P204 DIGITAL UTILITY SIGNALS SILENCED
256 EXT 2:1 COMNTBL TROUBLE COMMON TROUBLE POINT FOR NODE: 2
512 EXT 2:P601 DIGITAL UTILITY M1-1 ALARM
513 EXT 2:P602 DIGITAL UTILITY M1-2 ALARM
514 EXT 2:P603 DIGITAL UTILITY M1-3 ALARM
515 EXT 2:P604 DIGITAL UTILITY M1-4 ALARM
516 EXT 2:P605 DIGITAL UTILITY M1-5 ALARM
517 EXT 2:P606 DIGITAL UTILITY M1-6 ALARM
518 EXT 2:P607 DIGITAL UTILITY M1-7 ALARM
519 EXT 2:P608 DIGITAL UTILITY M1-8 ALARM
520 EXT 2:P609 DIGITAL UTILITY M1-9 ALARM
521 EXT 2:P610 DIGITAL UTILITY M1-10 ALARM
522 EXT 2:P611 DIGITAL UTILITY M1-11 ALARM
523 EXT 2:P612 DIGITAL UTILITY M1-12 ALARM
524 EXT 2:P613 DIGITAL UTILITY M1-13 ALARM
525 EXT 2:P614 DIGITAL UTILITY M1-14 ALARM
526 EXT 2:P615 DIGITAL UTILITY M1-15 ALARM
527 EXT 2:P616 DIGITAL UTILITY M1-16 ALARM
528 EXT 2:P617 DIGITAL UTILITY M1-17 ALARM
529 EXT 2:P618 DIGITAL UTILITY M1-18 ALARM
530 EXT 2:P619 DIGITAL UTILITY M1-19 ALARM
531 EXT 2:P620 DIGITAL UTILITY M1-20 ALARM
532 EXT 2:P621 DIGITAL UTILITY M1-21 ALARM
533 EXT 2:P622 DIGITAL UTILITY M1-22 ALARM
Table 16 NETWORK INTERFACE REPORT
To Next Page
