Page 74 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
7.3 SYSTEM TEST PROCEDURES
Note: These procedures should be followed when the system is first installed, during
periodic tests, or as required by local code. Check local codes to determine
how frequently your system should be tested. Always inform appropriate
personnel that you will be testing the system (city Fire Brigade, customer,
etc.).
7.4 LAMP TEST
The lamp test pushbutton on the control panel is used to determine local lamp
failures within the system. Only lamps on the 4100 control panel will illuminate along
with the five function and acknowledge LEDs. All segments on the LCD will also
change. Perform the following procedures to determine lamp failure:
(a) Press the “LAMP TEST” pushbutton.
All LEDs should illuminate (lamps should stay illuminated as long as the
pushbutton is depressed). Holding the Lamp Test pushbutton in for more
than three seconds will test the piezo.
(b) Perform an individual lamp test on all remote annunciators, to include the 24
point I/Os, RCUs, SCUs and LED/switch modules.
(c) Remove and replace defective lamp(s).
Note: The serial annunciator lamps/LEDs will not illuminate during the lamp test.
7.5 REMOUNTING RETAINER
(a) Install the retainer assembly onto the back box assembly utilising the two
bottom hook-tabs and secure it by using two plastic squeeze release tabs
located on the upper centre of the retainer assembly.
(b) Install two screws to secure the retainer assembly, one at the top centre of
the retainer assembly and the other at the bottom centre of the retainer
assembly.
Note: The two screws must be installed to ensure proper ESD (electro-static
discharge) protection.
(c) Close and lock the door assembly.
