Simplex 4100 - 3 Field Terminations; Speaker Line Terminations; Figure 12 Amplifier Card Terminations for Speakers

SIMPLEX 4100 EWIS Page 27
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
3. FIELD TERMINATIONS
This section describes procedures to successfully install and terminate all field
equipment that is to be terminated to the 4100 EWIS System.
3.1 SPEAKER LINE TERMINATIONS
Figure 12 Amplifier Card Terminations for Speakers
8225
or
8250
Amplifier
Card
10k End of Line
at last speaker in
100V
IN
100V
OUT
