Page 28 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
Speaker lines are terminated in the 8225 or 8250 Amplifier card.
Only one Zone can be terminated on each Amplifier card, speakers can be wired in
parallel, and terminated with a 10k End of Line Resistor.
The terminating connections are located at the bottom of the front panel on the
amplifier card (See
Figure 12).
Speakers are terminated across the 100v output line as shown in
