SIMPLEX 4100 EWIS Page 57
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
4.6 ANNUNCIATOR REPORT
The Local Annunciator Report is shown first (if applicable), followed by the Remote
Annunciator Report (if applicable). The first page of these reports shows the
controller/card number, position, and the type of display cards selected. The next
pages will show the point, switch mode, reference address, reference custom label,
and the reference type. A typical Local Annunciator Report is shown in Figure 7.
--------------------------------------------------------------------------------
XYZ BUILDING 1 CARD DETAIL REPORT Page 11
909015J node:1 rev:1 04:39:17, WED, 14-MAY-97
--------------------------------------------------------------------------------
CARD No: 5 LED/SW
(0301) 64 LED / 64 Sw Controller CARD
UNIT No: 0 5
addr 00000101
sw1 12345678
CONTROLLER CARD CONFIGURATION DETAIL:
Controller
Card No Display Card Display Card Type
---------- ------------ -----------------------------
5 1 L403 - 8 Momen Sw/8 Red LED
2 L405 - 8 Momen Sw/16 Red-Yel LED
3 L405 - 8 Momen Sw/16 Red-Yel LED
4 L405 - 8 Momen Sw/16 Red-Yel LED
5 0409 - Blank Display Card
6 0409 - Blank Display Card
7 0409 - Blank Display Card
8 0102 - Battery Meters (amp/volt)
9 0409 - Blank Display Card
10 0409 - Blank Display Card
11 0409 - Blank Display Card
12 0409 - Blank Display Card
13 0409 - Blank Display Card
14 0409 - Blank Display Card
15 0409 - Blank Display Card
16 0409 - Blank Display Card
Table 10 LOCAL ANNUNCIATOR REPORT
