Simplex 4100 - Telephone Operation

SIMPLEX 4100 EWIS Page 47
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
The Network Master WIP Phone is the start and finish of the WIP Phone Network.
The WIP Phone Network leaves the master Node from port P3 and is looped through
each slave node and returns to the master node on port P4. (See
Figure 19)
Figure 19 Master WIP Phone Network
