Simplex 4100 - Custom Control Equation Listing; Table 17 CUSTOM CONTROL EQUATION LISTING

Page 64 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
4.13 CUSTOM CONTROL EQUATION LISTING
The Custom Control Equation Listing displays the line by line Custom Control
equations for the system.
--------------------------------------------------------------------------------
XYZ BUILDING CUSTOM CONTROL EQUATION LISTING Page 156
2796 node:1 rev:6 14:41:55, WED, 25-MAR-98
--------------------------------------------------------------------------------
CUSTOM CONTROL
EQU DETAIL
Program: 7 Program: 7
Label: AUTO LED Equation 1
COMMENTS:
INPUTS:
OR the ON state of:
P1024 UTILITY KEYSWITCH - AUTO
P2 UTILITY FRONT PANEL LAMPTEST CONTROL (ANNUNC. 0)
P1027 UTILITY KEYSWITCH - AUTO LED
OUTPUTS:
TRACK points ON pri=9,9
16-152 UTILITY Ann 0 Pt 152 LED/SW Spec Output
END:
Label: ALERT/EVAC DELAY - NORMAL - 10 MINS Equation 2
COMMENTS:
AS 2220.1 STATES THE DELAY BETWEEN ALERT AND EVAC MUST NOT EXCEED 10
MINUTES
INPUTS:
NOT the ON state of:
P5 UTILITY SET SERVICE PSEUDO VALUES
OUTPUTS:
SET to value 600 (Secs) the analogs:
A267 ANALOG ALERT/EVAC CHANGEOVER VALUE
END:
Label: ALERT/EVAC DELAY - SERVICE - 15 SECS Equation 3
COMMENTS:
INPUTS:
The ON state of:
P5 UTILITY SET SERVICE PSEUDO VALUES
OUTPUTS:
SET to value 15 (Secs) the analogs:
A267 ANALOG ALERT/EVAC CHANGEOVER VALUE
END:
Label: * ENABLE alert/evac/cascade OPERATION * Equation 4
COMMENTS:
INPUTS:
The ON state of:
A34 TIMER SYSTEM STARTUP PULSE TIMER
OUTPUTS:
HOLD points ON pri=9,9
P1036 UTILITY ENABLE CASCADE OPERATION
Table 17 CUSTOM CONTROL EQUATION LISTING
