Page #61 background imageLoading...
Page #61 background image
SIMPLEX 4100 EWIS Page 53
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
4.3 SYSTEM POINT SUMMARY
The System Point Summary is of primary importance to the installer. Simplex
personnel must provide this information prior to installation. Call your local Simplex
branch office, which is listed in the Yellow Pages, and request this information be
provided. This is used in conjunction with the Layout pages, to determine wiring
terminations and the information shown below.
4.3.1 Zone Name
Zone names reference the custom label to specific points for actual customer wiring.
They include monitor zones (ZNx), signals (SIGx), auxiliary relays (AUXx), 24 point
I/O (PMx) and feedback (FBx) numbers. Zones, signals, relays, feedbacks, etc., are
shown in numerical sequence.
4.3.2 Address
Each printed circuit board requires a unique address. Address 0 identifies the
master termination module. Up to 119 addresses, one per printed circuit board, may
be used in a system. Addresses may or may not be in sequential order, but the
report always starts with address 0. Two address labels are used for each
mother/daughter board combination. The mother board will have its unique address
label next to the PC board connector. The daughter board will have an identical
label.
4.3.3 Custom Label
The custom label identifies a location within the building or area, and contains
additional information concerning each circuit. Also included with the custom label is
the corresponding zone name. This ties the custom label to a zone name and allows
the installer to identify where field wires are terminated, according to zone name.
__________________________________________________________
Examples: 1ST FLOOR SOUTH WING WIP SIGNAL 2
3RD FLOOR EAST WING ALERT STROBES SIGNAL 40_
4.3.4 Point Type
This is the type of device (indicating appliance, initiating device, relays, etc.)
connected to each circuit. Each device type is abbreviated. An operational
description may also be included in the abbreviation.
_____________________________________
Example: AHUM (Air Handling Unit Monitor)
PRI (Primary Elevator Capture)___
The installer should use the System Point Summary when marking wires to the 4100
panel. These markings should include zones (ZNx+, ZNx--), signals (SIGx), etc., for
each circuit within the system. Marking each wire in this matter will facilitate
termination and checking of the wiring in the 4100 panel.
