Page 56 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
4.5 UNIT DETAIL REPORT
The Unit Detail Report shows detailed information regarding each printed circuit
board as well as software cards (pseudos) in the system. Custom information is
shown for each type of card, such as card number, card address (binary), circuits on
the card, circuit types, custom labels, and coding information, if applicable.
--------------------------------------------------------------------------------
XYZ BUILDING UNIT DETAIL REPORT Page 62
2796 node:1 rev:6 14:41:55, WED, 25-MAR-98
--------------------------------------------------------------------------------
UNIT No: 0 UNIT 0
CARD No: 0 (base) 0-4
64 LED / 64 Sw Controller
CONTROL PANEL LED/SWITCH ANNUNCIATOR 0
UNIT COMPOSITION:
Card No Card Type Display Card Point Usage
------- ---------------------------------------- ------------------------
0 64 LED / 64 Sw Controller 0 LEDs / 0 SWs
6 (0301) 64 LED / 64 Sw Controller 64 LEDs / 32 SWs
7 (0301) 64 LED / 64 Sw Controller 64 LEDs / 40 SWs
14 (0301) 64 LED / 64 Sw Controller 64 LEDs / 40 SWs
16 (0301) 64 LED / 64 Sw Controller 64 LEDs / 40 SWs
17 (0301) 64 LED / 64 Sw Controller 64 LEDs / 32 SWs
18 (0301) 64 LED / 64 Sw Controller 0 LEDs / 0 SWs
1 (3003) 8 Pt, 3 Amp Relay w/ Feedback N/A
2 (0304) Remote Unit Interface (RUI) N/A
3 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
4 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
5 (6005) Power Supply/Charger N/A
8 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
9 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
10 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
11 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
12 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
13 (5002) 8 Zn Class B Monitor (IDC) w/Sup N/A
19 (4332) 3 Input Class A Signal w/Sup N/A
20 (4332) 3 Input Class A Signal w/Sup N/A
21 (4332) 3 Input Class A Signal w/Sup N/A
22 (4332) 3 Input Class A Signal w/Sup N/A
23 (4332) 3 Input Class A Signal w/Sup N/A
NOTE: Card 0, Annun 0 = Master Controller slot 4
Table 9 UNIT DETAIL REPORT

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
