Page 52 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
4.2 CARD SUMMARY BY LOCATION
The Card Summary by Location shows the number of cards within the system. This
page should be used to verify delivery of system cards from the factory. It also
shows a decimal card number which is the address for that printed circuit board.
Addresses 3 and 9 are shown below on Custom Terminal Wiring Identifiers.
--------------------------------------------------------------------------------
XYZ BUILDING CARD SUMMARY BY LOCATION Page 3
2796 node:1 rev:6 14:41:55, WED, 25-MAR-98
--------------------------------------------------------------------------------
CARD
CARD LOCATION LISTING: LOCATION
LOCAL CONTROLLER UNIT:
DAUGHTER CARDS:
Card Card Type Zone Range
----- ---------------------------------------- -----------------
0 (7003) 4100+ Master Controller
1 (3003) 8 Pt, 3 Amp Relay w/ Feedback AUX3-10
2 (0304) Remote Unit Interface (RUI) RUI 1
3 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN1-8
4 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN9-16
5 (6005) Power Supply/Charger
8 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN17-24
9 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN25-32
10 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN33-40
11 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN41-48
12 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN49-56
13 (5002) 8 Zn Class B Monitor (IDC) w/Sup ZN57-64
15 (0205) Phone Card
19 (4332) 3 Input Class A Signal w/Sup SIG3-8
20 (4332) 3 Input Class A Signal w/Sup SIG9-14
21 (4332) 3 Input Class A Signal w/Sup SIG15-20
22 (4332) 3 Input Class A Signal w/Sup SIG21-26
23 (4332) 3 Input Class A Signal w/Sup SIG27-32
ANNUNCIATORS:
Annun Card Card Type Zone Range
----- ----- ---------------------------------------- -----------------
0 0 64 LED / 64 Sw Controller
6 (0301) 64 LED / 64 Sw Controller
7 (0301) 64 LED / 64 Sw Controller
14 (0301) 64 LED / 64 Sw Controller
16 (0301) 64 LED / 64 Sw Controller
17 (0301) 64 LED / 64 Sw Controller
18 (0301) 64 LED / 64 Sw Controller
REMOTE UNIT INTERFACE 1 (RUI 1):
Type Unit Card Card Type Zone Range
--------- ---- ---------------------------------------- -----------------
Ann 1 24 (0302) 24 Pt Graphic Interface IO1-24
Ann 1 26 (0302) 24 Pt Graphic Interface IO25-48
Ann 1 27 (0302) 24 Pt Graphic Interface IO49-72
Ann 1 25 (6005) Power Supply/Charger
Table 6 CARD SUMMARY BY LOCATION REPORT
