Page 50 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
Figure 21 WIP Network Slave Node Phone Terminations
The Master Phone Handset terminations are on terminals labelled 1 & 2.
The positive line on terminal 1 and the negative line on terminal 2.
3.9 SECP TERMINATION
SECP terminations are site configuration dependent and will be designated at time of
system configuration.
