Page 58 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
4.7 DIGITAL PSEUDO POINT SUMMARY
The Digital Pseudo Point Summary shows all digital pseudo points within the system.
It also identifies the custom labels, and pseudo type for each digital pseudo point
within the system.
--------------------------------------------------------------------------------
XYZ BUILDING DIGITAL PSEUDO POINT SUMMARY Page 20
2796 node:1 rev:6 14:41:55, WED, 25-MAR-98
--------------------------------------------------------------------------------
CARD No: 132 DIGITAL SUMMARY
256 Point Digital Pseudo P1024 - P1075
Point Custom Label Type PNIS Codes
------- ---------------------------------------- --------- -----------
P1024 KEYSWITCH - AUTO UTILITY
P1025 E.W.S KEYSWITCH IN MANUAL POSITION TROUBLE
P1026 E.W.S KEYSWITCH IN ISOLATE POSITION SUPERV
P1027 KEYSWITCH - AUTO LED UTILITY
P1028 ALL ALERT - MANUAL UTILITY
P1029 ALL EVAC - MANUAL UTILITY
P1030 ALL P.A. - MANUAL UTILITY
P1031 ALL CANCEL - MANUAL UTILITY
P1033 ALL ALERT LED UTILITY
P1034 ALL EVAC LED UTILITY
P1035 ALL P.A. LED UTILITY
P1036 ENABLE CASCADE OPERATION UTILITY
P1037 ALL CALL - RING THE PHONES UTILITY
P1038 ALL CALL - TALK TO ALL PHONES UTILITY
P1040 AMP 1 FAULT LED UTILITY
P1041 AMP 2 FAULT LED UTILITY
P1042 AMP 3 FAULT LED UTILITY
P1043 AMP 4 FAULT LED UTILITY
P1044 AMP 5 FAULT LED UTILITY
P1045 AMP 6 FAULT LED UTILITY
P1046 AMP 7 FAULT LED UTILITY
P1047 AMP 8 FAULT LED UTILITY
P1048 AMP 9 FAULT LED UTILITY
P1049 AMP 10 FAULT LED UTILITY
P1050 AMP 11 FAULT LED UTILITY
P1051 AMP 12 FAULT LED UTILITY
P1052 AMP 13 FAULT LED UTILITY
P1053 AMP 14 FAULT LED UTILITY
P1054 AMP 15 FAULT LED UTILITY
P1055 AMP 16 FAULT LED UTILITY
P1060 SPEAKER LINE SHORTED - AMP #1 DISABLED TROUBLE
P1061 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #1 TROUBLE
P1062 SPEAKER LINE SHORTED - AMP #2 DISABLED TROUBLE
P1063 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #2 TROUBLE
P1064 SPEAKER LINE SHORTED - AMP #3 DISABLED TROUBLE
P1065 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #3 TROUBLE
P1066 SPEAKER LINE SHORTED - AMP #4 DISABLED TROUBLE
P1067 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #4 TROUBLE
P1068 SPEAKER LINE SHORTED - AMP #5 DISABLED TROUBLE
P1069 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #5 TROUBLE
P1070 SPEAKER LINE SHORTED - AMP #6 DISABLED TROUBLE
P1071 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #6 TROUBLE
P1072 SPEAKER LINE SHORTED - AMP #7 DISABLED TROUBLE
P1073 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #7 TROUBLE
P1074 SPEAKER LINE SHORTED - AMP #8 DISABLED TROUBLE
P1075 SPEAKER LINE OPEN CIRCUIT - AMPLIFIER #8 TROUBLE
Table 11 DIGITAL PSEUDO POINT SUMMARY
4.8 ANALOG PSEUDO POINT SUMMARY
