4.10 POINT LIST DETAIL
The Point List Detail identifies each list (with points identified) within the Point List
Summary. It shows the list number, points within the list, custom point labels, and
type of device connected to the circuit.
--------------------------------------------------------------------------------
XYZ BUILDING POINT LIST DETAIL Page 32
2796 node:1 rev:6 14:41:55, WED, 25-MAR-98
--------------------------------------------------------------------------------
CARD No: 160 L18 POINT LIST
256 Point List Pseudo
LIST No: 18 L18
continued
Description: GENERAL FIRE ALARM MONITOR ZONES
Device Point
Point Custom Point Label Type Type
----------- ---------------------------------------- ------- -------
ZN1 MONITOR CARD 3 ZONE NUMBER 1 MONB FIRE
ZN2 MONITOR CARD 3 ZONE NUMBER 2 MONB FIRE
ZN3 MONITOR CARD 3 ZONE NUMBER 3 MONB FIRE
ZN4 MONITOR CARD 3 ZONE NUMBER 4 MONB FIRE
ZN5 MONITOR CARD 3 ZONE NUMBER 5 MONB FIRE
ZN6 MONITOR CARD 3 ZONE NUMBER 6 MONB FIRE
ZN7 MONITOR CARD 3 ZONE NUMBER 7 MONB FIRE
ZN8 MONITOR CARD 3 ZONE NUMBER 8 MONB FIRE
ZN9 MONITOR CARD 4 ZONE NUMBER 9 MONB FIRE
ZN10 MONITOR CARD 4 ZONE NUMBER 10 MONB FIRE
ZN11 MONITOR CARD 4 ZONE NUMBER 11 MONB FIRE
ZN12 MONITOR CARD 4 ZONE NUMBER 12 MONB FIRE
ZN13 MONITOR CARD 4 ZONE NUMBER 13 MONB FIRE
ZN14 MONITOR CARD 4 ZONE NUMBER 14 MONB FIRE
ZN15 MONITOR CARD 4 ZONE NUMBER 15 MONB FIRE
ZN16 MONITOR CARD 4 ZONE NUMBER 16 MONB FIRE
ZN17 MONITOR CARD 8 ZONE NUMBER 17 MONB FIRE
ZN18 MONITOR CARD 8 ZONE NUMBER 18 MONB FIRE
ZN19 MONITOR CARD 8 ZONE NUMBER 19 MONB FIRE
ZN20 MONITOR CARD 8 ZONE NUMBER 20 MONB FIRE
ZN21 MONITOR CARD 8 ZONE NUMBER 21 MONB FIRE
ZN22 MONITOR CARD 8 ZONE NUMBER 22 MONB FIRE
ZN23 MONITOR CARD 8 ZONE NUMBER 23 MONB FIRE
ZN24 MONITOR CARD 8 ZONE NUMBER 24 MONB FIRE
ZN25 MONITOR CARD 9 ZONE NUMBER 25 MONB FIRE
ZN26 MONITOR CARD 9 ZONE NUMBER 26 MONB FIRE
ZN27 MONITOR CARD 9 ZONE NUMBER 27 MONB FIRE
ZN28 MONITOR CARD 9 ZONE NUMBER 28 MONB FIRE
ZN29 MONITOR CARD 9 ZONE NUMBER 29 MONB FIRE
ZN30 MONITOR CARD 9 ZONE NUMBER 30 MONB FIRE
ZN31 MONITOR CARD 9 ZONE NUMBER 31 MONB FIRE
ZN32 MONITOR CARD 9 ZONE NUMBER 32 MONB FIRE
ZN33 MONITOR CARD 10 ZONE NUMBER 33 MONB FIRE
ZN34 MONITOR CARD 10 ZONE NUMBER 34 MONB FIRE
ZN35 MONITOR CARD 10 ZONE NUMBER 35 MONB FIRE
ZN36 MONITOR CARD 10 ZONE NUMBER 36 MONB FIRE
ZN37 MONITOR CARD 10 ZONE NUMBER 37 MONB FIRE
ZN38 MONITOR CARD 10 ZONE NUMBER 38 MONB FIRE
ZN39 MONITOR CARD 10 ZONE NUMBER 39 MONB FIRE
ZN40 MONITOR CARD 10 ZONE NUMBER 40 MONB FIRE
ZN41 MONITOR CARD 11 ZONE NUMBER 41 MONB FIRE
ZN42 MONITOR CARD 11 ZONE NUMBER 42 MONB FIRE
Table 14 POINT LIST DETAIL
