SIMPLEX 4100 EWIS Page 1
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
1. INTRODUCTION
This manual provides information for the personnel engaged in the installing,
commissioning and maintenance of the 4100 EWIS and is to be used in conjunction
with the 4100 Operators Manual.
It is assumed that users of this manual are:
a) Familiar with the operation of the 4100 EWIS Panel.
b) Trained to install and service microprocessor based EWIS and fire alarm
equipment.
NOTES:
A. Indexes for the 4100 Field Wiring Diagram are found on the first page of
the document.
B. All wiring must be in accordance with local codes.
C. A page entitled “GENERAL WIRING PRECAUTIONS” is included in the
4100 Field Wiring Diagram.
If possible, proceed through the installation process in the sequence that follows.
1.1 UNPACKING INVENTORY AND INSPECTION
Carefully check packing prior to unpacking goods for any external transit damage.
Unpack the goods and check the goods both externally and internally for any loose
or damaged components or any problems which may effect the appearance,
installation or operation of the goods.
Ensure all wiring harnesses are secure, all plugs are correctly fitted into their
sockets, each circuit board is secure, and that all fixings and earth studs are tight.
If a plug-in type circuit board or ribbon connector becomes dislodged in transit,
replace it in is socket and ensure that it is correctly mated.
If any damage has occurred you are to contact Simplex.
* * * IMPORTANT * * *
The contractor IS NOT responsible for inventorying or installing daughter cards, or for interconnecting
panel components.
• All cartons that contain daughter cards are to be opened, inventoried, and
installed by Simplex personnel.
