Simplex 4100 Installation Manual

SIMPLEX 4100 EWIS Page 79
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
FAULT / STATUS POSSIBLE CAUSE SOLUTION
Communication Fault
• Section of the RS 485
loop faulty or
disconnected from
module.
• Check section and
termination, or field
wiring.
• Check internal comms
connections.
• Ensure all modules are
plugged in.
Ensure modules are
installed in correct
order.
System Fault
• Module or CPU within
entire system faulty
• Identify MECP or
SECP display module
or CPU fault. Ref
module fault or CPU
fault instructions.
Module Fault
• Faulty Module • Replace Module
EWIS Zone Fault in
Amplifier / Speaker.
• Speaker cabling fault.
• Short or Open circuit
cable.
• No EOL resistor.
• No DC isolation
capacitor fitted
(incorrect speaker
type).
Amplifier Faulty
• Faulty amplifier
• Blown fuse.
• Check as instructed in
installation manual.
• Fit 10k EOL resistor.
• Fitted capacitors or
change speaker.
• Replace amplifier.
• Replace fuse.
5 amp 3AG.

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
