Page 66 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
To power up the 4100 system, perform the following steps:
(a) Ensure that the mains isolate switch is OFF and batteries are disconnected.
Ensure that 240V AC supply is connected to the panel from the mains
distribution board.
(b) Turn the panel mains isolate switch ON. When the green Power LED turns
on (after approximately 30 seconds), connect the batteries.
(c) Acknowledge all abnormal conditions by pressing the appropriate “ACK”
(Alarm and Fault) pushbutton(s). Press the “ACK” pushbutton to review all
abnormal conditions within each list. Once all abnormal conditions are
cleared, press the “CLR” key.
(d) Set the correct time and date. The system should then display “SYSTEM IS
NORMAL” followed by the time and date.
(e) Repair/restore all abnormal conditions. (refer Appendix A - Trouble shooting
Procedures )

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
