Simplex 4100 Installation Manual

SIMPLEX 4100 EWIS Page 11
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
13. Mount the door on the back box using the following procedure (See Figure 7).
a) Lift and place the front door assembly bottom pin into back box hinge hole.
b) Lift and slide top bolt pin up and across to lower bolt pin.
c) Move front door assembly into place.
d) Lift top bolt pin up into locating hole, and slide bolt pin across to drop bolt pin
into holding plate.
e) The door is now mounted onto the back box.

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
