SIMPLEX 4100 EWIS Page 33
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
One Zone can terminate many Manual Call Points, but they must be wired in parallel,
and terminated with a 3k3 End of Line Resistor across the last manual call point.
The terminating connections are located at the Top and Bottom of the motherboard.
