Page 38 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
Visual Alarm Devices are terminated in the 4100-4322-signal card.
There are 6 signal ports per card and are labelled SIGx to SIGx. Where x
corresponds to a signal port number.
Visual Alarm Devices are terminated on each port of the signal card.
For each Evacuation Zone, two signal ports are assigned.
1. For the Alert Strobe(s)
2. For Evacuation Strobe(s)
Each Visual Alarm Device must terminated with a 10k End of Line Resistor.
The terminating connections are located at the Top and Bottom of the motherboard.
Each port can source up to 2 Amps at 24 VDC for driving strobes.
If driving a number of strobes, ensure that the correct size cable is used to minimise
voltage drop on the unit.
