Page 40 SIMPLEX 4100 EWIS
INSTALLATION MANUAL
Document No.: 4100-M011 March 1998 Issue 1.0
WIP Devices are terminated in the 4100-4322-signal card.
There are 6 ports per card and are label SIG3 to SIG8. The cable shields should be
connected in the termination labelled SHLD (See
Figure 16).
Only One WIP phone can be terminated on each port of the signal card. These
phones must be Simplex WIP phones Part Number: - 2084-9106.
