Skyjack SJ63 AJ+ Service Manual

165
SJ63 AJ+, SJ63 AJ 229043AAA
Electrical System - CE & AS Section 4 – Troubleshooting Information
4.3-47 High Throttle Inoperative
1. Loose or broken wire #08 from platform terminal
block to throttle switch S10.
Check continuity. Replace if defective.
2. Open or defective diode D08. (Generator option
only)
Check diode. Replace if defective.
3. Defective throttle switch S10. Check continuity through switch while activating
high throttle function between wires #08 and #78.
If no continuity found replace switch.
4. Loose or broken wire #78 from throttle switch
S10 to plug B pin #19 in platform control
console.
Check continuity. Replace if defective.
5. Loose or broken wire #78 in Cable B or its
connectors.
Check for continuity between pins #19 on cable B.
Check for loose or corroded connections on cable
connectors. Replace if wire is defective.
Deutz Diesel Only:
6. Loose or broken wire #78 from base plug B pin
#19 to relay 78CR.
Check continuity. Replace if defective.
7. Loose or broken wire #02 from base terminal
block to relay 78CR.
Check continuity. Replace if defective.
8. Loose or broken wire #90 from relay 78CR to
ECU connector pin #21.
Check continuity. Replace if defective.
9. Loose or broken wire #103 from relay 78CR to
base terminal block.
Check continuity. Replace if defective.
10. Loose or broken wire #103 from base terminal
block to ECU connector pin #17.
Check continuity. Replace if defective.
11. Defective relay 78CR. Check relay. Replace if defective.
GM Engine Only:
12. Loose or broken wire #78 from base plug B pin
#19 to engine harness plug.
Check continuity. Replace if defective.
13. Loose or broken wire #78 from engine harness
plug to GM engine connector 2.
Check continuity. Replace if defective.
14. Loose or broken gray/orange wire from GM
engine connector 2 to ECU connector pin #52.
Check continuity. Replace if defective.
15. Loose or broken light blue/dark blue wire from
ECU connector pin #6 to throttle actuator RA1.
Check continuity. Replace if defective.
16. Defective throttle actuator RA1. Check actuator. Replace if defective.
