Skyjack SJ63 AJ+ Service Manual

284
SJ63 AJ+, SJ63 AJ229043AAA
Section 5 – Procedures Axles
5.10-4 Check the Oil Level in the Axle
Gearbox
1. Remove the fill plug
1
from the gear box.
2. Check the oil level. It should be even with the
bottom of the fill plug hole. Add oil if needed.
Refer to 2.11 Hydraulic Specifications & Gear Oil
for oil specifications.
5.10-5 Change the Oil in the Axle Gearbox
1. Place a suitable container under the gearbox.
2. Remove the fill plug.
3. Remove the drain plug to allow oil to drain into
the container.
Drain Port
Fill/Check Port
4. Reinstall the drain plug.
NOTE
The gearbox is full when oil is leaking from the
check port.
5. Refill the gearbox with new oil as per
specifications. Refer to 2.11 Hydraulic
Specifications & Gear Oil.
6. Reinstall the fill plug.
1
