Skyjack SJ63 AJ+ Service Manual

55
SJ63 AJ+, SJ63 AJ 229043AAA
Hydraulic Parts List Section 3 – System Component Identification and Schematics
3.4 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
2H-13A 159838 VALVE, Flow Control (Main boom lowering)
2H-21A 159821 VALVE, Control (Enable)
2H-21B 194492 VALVE, Control (Load Circuit Select)
2H-42 231438 VALVE, Control (Platform Flow Enable)
2H-85 146078 VALVE, Control (3.5kW Generator)
2H-85 168058 VALVE, Control (12kW Generator)
3H-26 159827 VALVE, Control (Brake release)
3H-45 159827 VALVE, Control (2 Speed motor)
3H-65 159827 VALVE, Control (Axle lockout)
3H-165 159827 VALVE, Control (Differential lockout)
4H-15 N/A VALVE, Control (Drive pump displacement control - reverse)
4H-16 N/A VALVE, Control (Drive pump displacement control - forward)
5H-13 159820 VALVE, Control (Main boom lower)
5H-14 159820 VALVE, Control (Main boom raise)
5H-23A 159819 VALVE, Control (Steering right)
5H-24A 159819 VALVE, Control (Steering left)
5H-30 159820 VALVE, Control (Riser boom lower)
5H-31 159820 VALVE, Control (Riser boom raise)
5H-32 159819 VALVE, Control (Boom rotation left)
5H-33 159819 VALVE, Control (Boom rotation right)
5H-38 159822 VALVE, Control (Fly boom retract)
5H-39 159822 VALVE, Control (Fly boom extend)
5H-40 159819 VALVE, Control (Platform level lower)
5H-41 159819 VALVE, Control (Platform level raise)
C1 160091 CYLINDER (Jib boom)
C2 154207 CYLINDER (Fly boom)
C3 153530 CYLINDER (Main boom)
C4 153533 CYLINDER (Platform leveling - master)
C5 153535 CYLINDER (Platform leveling - slave)
C6 153534 CYLINDER (Riser boom)
C7 153534 CYLINDER (Riser boom)
C8 N/A CYLINDER (Front axle steering)
C9 212871 CYLINDER (Axle lockout)
C10 212871 CYLINDER (Axle lockout)
C11 N/A CYLINDER (Brake release)
C12 N/A CYLINDER (Brake release)
C13 N/A CYLINDER (Differential lock)
CB1 149488 VALVE, Counterbalance (Jib cylinder)
CB2 149488 VALVE, Counterbalance (Jib cylinder)
CB3 141499 VALVE, Counterbalance (Swing drive)
CB4 141499 VALVE, Counterbalance (Swing drive)
CB5 149488 VALVE, Counterbalance (Riser cylinder)
CB6 149488 VALVE, Counterbalance (Riser cylinder)
CB7 141453 VALVE, Counterbalance (Fly boom)
CB8 141453 VALVE, Counterbalance (Fly boom)
