Skyjack SJ63 AJ+ Service Manual

56
SJ63 AJ+, SJ63 AJ229043AAA
Section 3 – System Component Identification and Schematics Wire Number and Color Code
3.4 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
CB9 159841 VALVE, Counterbalance (Main boom)
CB10 710088 VALVE, Counterbalance (Platform levelling cylinder - slave)
CB11 710088 VALVE, Counterbalance (Platform levelling cylinder - slave)
CB12 141399 VALVE, Counterbalance (Platform rotary actuator)
CB13 141399 VALVE, Counterbalance (Platform rotary actuator)
CB14 212872 VALVE, Counterbalance (Axle lockout cylinder)
CB15 212872 VALVE, Counterbalance (Axle lockout cylinder)
CV1 159813 VALVE, Check (Main inlet)
CV2 159814 VALVE, Check (Steer load sense)
CV3 159814 VALVE, Check (Swing drive load sense)
CV4 159814 VALVE, Check (Platform levelling override drain)
CV5 159814 VALVE, Check (Main boom load sense)
CV6 159814 VALVE, Check (Fly boom load sense)
CV7 159814 VALVE, Check (Platform levelling override load sense)
CV8 159814 VALVE, Check (Jib boom load sense)
CV9 159814 VALVE, Check (Riser boom load sense)
CV10 159815 VALVE, Check (Jib boom/platform rotate drain)
CV11 159813 VALVE, Check (Throttle bypass)
CV12 N/A VALVE, Check (EPU outlet)
CV13 159842 VALVE, Check (Counterbalance bypass)
CV14 159814 VALVE, Check (Generator LS)
CV15 168059 VALVE, Check (Generator)
DPOCV1 159817 VALVE, Dual pilot operated check (Steering)
DPOCV2 159817 VALVE, Dual pilot operated check (Platform levelling)
DSV1 159816 VALVE, Differential sensing (Swing drive)
DSV2 159816 VALVE, Differential sensing (Riser boom)
DSV3 159816 VALVE, Differential sensing (Main boom)
DSV4 159816 VALVE, Differential sensing (Fly boom)
EPU 167433 POWER UNIT, Emergency
F1 139148 FILTER, High pressure (10 micron abs, 87 psi bp)
F2 153929 FILTER, Return (10 micon abs, 25 psi bp)
FC1 159838 VALVE, Flow control (Main boom lowering)
G1 703725 GAUGE, Pressure (800 psi)
GCV1 138405 VALVE, Control (Generator)
GCV2 168401 VALVE, Control (Generator)
M1 154138 MOTOR, Drive (Dual displacement)
M2 145981 MOTOR, Turret rotation
M3 N/A MOTOR, 3.5kW Hydraulic Generator
M4 N/A MOTOR, 12kW Hydraulic Generator
M5 N/A MOTOR, 12kW Hydraulic Generator
MB1 218406 MANIFOLD, Main control
MB2 153804 MANIFOLD, Brake control
MB3 149380 MANIFOLD, Rotary
MB4 153814 MANIFOLD, High pressure shuttle
MB5 231501 MANIFOLD, Jib cylinder
MP 159831 HAND PUMP, Brake
