SJ63 AJ+, SJ63 AJ 229043AAA
Wire Number and Color Code Section 3 – System Component Identification and Schematics
3.4 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
OC1 139092 OIL COOLER, Hydraulic
OR1 N/A ORIFICE, Motor swash plate (0.015”)
OR2 159825 ORIFICE, Differential sensing (0.030”)
OR3 159824 ORIFICE, Platform override speed (0.040”)
OR4 159823 ORIFICE, Jib boom speed (0.078”)
OR5 N/A ORIFICE, Platform rotate speed (0.038”)
OR6 144474 ORIFICE, Generator load sense (0.028”)
OR7 146077 ORIFICE, Generator flow control
OR8 194493 VALVE, Needle
OR9 171450 VALVE, Flow regulator (FR)
P1 154119 PUMP, Drive
P1A N/A PUMP, Charge
P2 154120 PUMP, System
PR1 159829 VALVE, Pressure reducing (500 psi)
QD1 122420 QUICK DISCONNET
RA1 218126 ROTARY ACTUATOR, Platform
RA2 138280 ROTARY ACTUATOR, Turret rotation
RV1 159808 VALVE, Relief (System)
RV2 159811 VALVE, Relief (Swing drive)
RV3 159809 VALVE, Relief (Levelling)
RV4 159811 VALVE, Relief (Riser boom)
RV5 159811 VALVE, Relief (Main boom)
RV6 159810 VALVE, Relief (Fly boom)
RV7 159828 VALVE, Relief (Brake pressure)
RV8 N/A VALVE, Relief (Forward drive pressure)
RV9 N/A VALVE, Relief (Reverse drive pressure)
RV10 N/A VALVE, Relief (Charge pressure)
RV11 170925 VALVE, Relief (EPU)
SV1 159812 VALVE, Shuttle (Platform relief)
SV2 159812 VALVE, Shuttle (Brake release override reset)
SV3 159833 VALVE, Shuttle (Brake pressure)
SV4 146014 VALVE, Shuttle (Swing drive)
SV5 N/A VALVE, Shuttle (Motor flush)
SV6 138394 VALVE, Shuttle (Generator load sense)
SV7 138394 VALVE, Shuttle
V1 141436 VALVE, Brake release override
V2 N/A VALVE, Pressure compensator
V3 N/A VALVE, Load sense compensator
V4 N/A VALVE, Towing bypass
V5 N/A VALVE, Minimum displacement select
V6 N/A VALVE, Hot oil exchange
V7 159805 VALVE, Enable
V8 159807 VALVE, Steering
V9 159807 VALVE, Boom rotation
V10 159806 VALVE, Riser elevation
V11 159806 VALVE, Main boom elevation
