Section 2 – Maintenance Tables and Diagrams Specifications & Features - Dimensions & Speeds
SJ63 AJ+ ANSI/CSA SJ63 AJ CE SJ63 AJ AS
Height & Reach
Working Height 69' 7" 21.21 m 21.38 m 21.38 m
Platform Height 63' 7" 19.38 m 19.38 m 19.38 m
Horizontal Reach - Maximum 40' 12.19 m 12.19 m 12.19 m
Horizontal Reach - Maximum Height 15' 9" 4.80 m 4.80 m 4.80 m
Horizontal Reach - Fly Boom Retracted 23' 4" 8.33 m 8.33 m 8.33 m
Tailswing 0 0 0 0
Up and Over Clearance - Platform 27' 6" 8.38 m 8.38 m 8.38 m
Up and Over Clearance - Main Boom 27' 2" 8.31 m 8.31 m 8.31 m
Platform
Platform Size
36" x 72"
36" x 96"
0.91 m x 1.83 m
0.91 m x 2.44 m
0.91 m x 1.83 m
0.91 m x 2.44 m
0.91 m x 1.83 m
0.91 m x 2.44 m
Platform Rotation 175° 175° 175° 175°
Platform Rotation Radius 45" 1.14 m 1.14 m 1.14 m
Platform Height - Stowed 11" 0.28 m 0.28 m 0.28 m
Overall Railing Height 53" 1.35 m 1.35 m 1.35 m
Platform Railing Height 44" 1.12 m 1.12 m 1.12 m
Dimensional Data
Height - Stowed 8' 4" 2.54 m 2.54 m 2.54 m
Length - Stowed 30' 9.14 m 9.14 m 9.14 m
Width 8' 2.44 m 2.44 m 2.44 m
Wheelbase 8' 2.44 m 2.44 m 2.44 m
Ground Clearance - Chassis 14.5" 0.37 m 0.37 m 0.37 m
Ground Clearance - Rear Axle 13" 0.33 m 0.33 m 0.33 m
Axle Oscillation 3.2" 0.08 m 0.08 m 0.08 m
Turning Radius - Inside 7' 3" 2.21 m 2.21 m 2.21 m
Turning Radius - Outside 17' 5" 5.31 m 5.31 m 5.31 m
Turret Rotation 360° 360° 360° 360°
Lift Capacity
Lift Capacity - to 45% grade 500 lbs 227 kg 227 kg 227 kg
Jib
Jib Length 5' 3" 1.60 m 1.68 m 1.68 m
Jib Vertical Range of Motion 9' 2-1/2" 2.81 m 2.98 m 2.98 m
Jib Range of Motion - down 60° 60° 60° 60°
Jib Range of Motion - up 65° 65° 65° 65°
Weight
Weight with Foam Tires - No Options 22,560 lbs 10 250 kg 10 200 kg 9 934 kg
2047AA
2.12 Specifications & Features - Dimensions & SpeedsTable
