Skyjack SJ63 AJ+ Service Manual

237
SJ63 AJ+, SJ63 AJ 229043AAA
Turret Section 5 – Procedures
5.5-4 Check the Swing Drive Oil
1. Remove the plug from the fill port
1
on the
back of the swing drive.
2. Check the oil level. The oil level should be
slightly below the port threads.
3. Add oil if needed. Refer to 2.11 Hydraulic
Specifications & Gear Oil for recommended oil
types.
1
5.5-5 Change the Swing Drive Oil
NOTE
The oil change must be performed on a flat, level
surface.
1. Remove the plug at the fill port
1
.
2. Place a suitable container under the drain
port
2
.
1
2
3. Remove the plug at the drain port.
4. Allow the oil to drain.
5. Reinstall the drain plug.
6. Refill the swing drive with approximately 1 L (32
oz) of oil. Refer to 2.11 Hydraulic Specifications
& Gear Oil for recommended oil types.
7. Reinstall the plug at the fill port.
