Skyjack SJ63 AJ+ Service Manual

197
SJ63 AJ+, SJ63 AJ 229043AAA
Platform Section 5 – Procedures
5.2-3 OCM Character Functions Charts
SCM Keypad
Keys Short Form
Menu/Select (M/S)
/-
(-)
/+
(+)
Save/Exit (S/E)
1345AA
Function Attribute
THRESH Threshold
RAMPDN Ramp Down
RAMPUP Ramp Up
LOWRNG Low Range
MAXOUT Maximum Output
5.2-4 OCM Function Channel Names - CE & AS
SCM Function (Channel) Names
DRIVE REV Fn01A Drive Reverse
DRIVE FWD Fn01B Drive Forward
CHAN 2A Fn02A Brakes
CHAN 2B Fn02B Differential Lock Enable
BOOM DOWN Fn03A Main Boom Down
BOOM UP Fn03B Main Boom Up
ROTATE L Fn04A Turret Rotate Left
ROTATE R Fn04B Turret Rotate Right
RISER DN Fn05A Riser Down
RISER UP Fn05B Riser Up
RISER UP Fn06A Virtual channel
RISER UP Fn06B Virtual channel
1346AA
